3 Years Warranty

Product Overview:

• Name: AMD Ryzen™ 5 7600X
• Family: Ryzen
• Series: Ryzen 7000 Series
• Form Factor: Desktop (Boxed Processor)
• Market Segment: Enthusiast Desktop
• Former Codename: Raphael AM5
• Processor Architecture: Zen 4
• Global Availability

CPU Specifications:

• Total Cores: 6
• Total Threads: 12
• Base Clock: 4.7 GHz
• Max Boost Clock: Up to 5.3 GHz
• L1 Cache: 384 KB
• L2 Cache: 6 MB
• L3 Cache: 32 MB
• Default TDP: 105 W
• CPU Boost Technology: Precision Boost 2

Manufacturing & Design:

• CPU Core Process: TSMC 5 nm FinFET
• I/O Die Process: TSMC 6 nm FinFET
• CPU Compute Die (CCD) Size: 71 mm²
• I/O Die (IOD) Size: 122 mm²
• Package Die Count: 2

Platform & Expansion:

• CPU Socket: AM5
• Supported Chipsets: A620, B650, B650E, X670, X670E, X870, X870E, B840, B850
• PCI Express Version: PCIe® 5.0
• Native PCIe® Lanes: 28 total (24 usable)
• Additional PCIe Lanes (Chipset Dependent)
• X670E / X670: Up to 12× Gen4
• B650E / B650: Up to 8× Gen4
• NVMe Support: Boot, RAID 0, RAID 1, RAID 10

Memory Specifications:

• System Memory Type: DDR5
• Memory Channels: 2
• Max Memory Capacity: 128 GB
• Memory Subtype: UDIMM
• Max Memory Speed (2×1R / 2×2R): DDR5-5200
• Max Memory Speed (4×1R / 4×2R): DDR5-3600
• ECC Support: Yes (Requires motherboard support)
• AMD EXPO™ Memory Overclocking: Supported

Connectivity:

• Native USB 3.2 Gen 2 (10 Gbps): 4 Ports
• Native USB 3.2 Gen 1 (5 Gbps): 0 Ports
• Native USB 2.0: 1 Port
• Native SATA Ports: 0

Graphics:

• Graphics Model: AMD Radeon™ Graphics
• Graphics Core Count: 2
• Graphics Frequency: 2200 MHz
• USB Type-C® DisplayPort™ Alternate Mode: Supported

Advanced Technologies:

• Simultaneous Multithreading (SMT): Yes
• Unlocked for Overclocking: Yes
• Precision Boost Overdrive: Yes
• Curve Optimizer Voltage Offsets: Yes
• AMD Ryzen™ Master Support: Yes
• Instruction Set: x86-64
• Supported Extensions: AES, AMD-V, AVX, AVX2, AVX-512, FMA3, MMX-plus, SHA, SSE, SSE2, SSE3, SSSE3, SSE4.1, SSE4.2, SSE4A
• Max Operating Temperature (Tjmax): 95°C

Cooling & OS Support:

• Included Cooler: Not Included
• Recommended Cooler: Premium air cooler for optimal performance
• Windows 11 (64-bit)
• Windows 10 (64-bit)
• RHEL x86 64-bit
• Ubuntu x86 64-bit

Additional Information:

• Launch Date: 27 September 2022
• AMD PRO Technologies: Not Supported
