Brand:

• MSI

Model:

• MAG PANO M100L PZ

Case Form Factor:

• Micro-ATX Tower

Motherboard Form Factor Support:

• Micro-ATX (Back-connect supported)
• Mini-ITX

I/O Ports:

• 1 x USB 3.2 Gen 1 Type-A
• 1 x USB 3.2 Gen 2×2 Type-C
• 1 x Audio-Out / Mic-In
• 1 x Reset Button
• 1 x Power Button

Drive Mount Support:

• 1 x 2.5”
• 1 x 2.5” / 3.5” Combo Bay
• (Up to 2 x 2.5” OR 1 x 2.5” + 1 x 3.5”)

Expansion Slots:

• 5 Slots

Maximum GPU Length:

• 390 mm (15.35 inches)
• Supports horizontal installation only

Maximum CPU Cooler Height:

• 175 mm (6.9 inches)

Power Supply Support:

• ATX PSU

Maximum PSU Length:

• 200 mm (7.87 inches)

Fan Support:

• Top: 3 x 120mm / 2 x 140mm
• Rear: 1 x 120mm / 1 x 140mm
• Side: 3 x 120mm
• Bottom: 1 x 120mm
• PSU Shroud: 2 x 120mm
• Front: Not Supported

Radiator Support:

• Top: 120 / 240 / 360 mm
• Rear: 120 / 140 mm
• Front: Not Supported
• Side: Not Supported
• Bottom: Not Supported

Dimensions (D x W x H):

• 488 x 235 x 453 mm
• 19.21 x 9.25 x 17.84 inches

Net Weight:

• 8.8 kg

Gross Weight:

• 11.54 kg
